The common nails is suitable for hard and soft wood, bamboo pieces, or plastic, wall foundry, repairing Furniture, packaging etc.Widely used in construction, decoration,and renovation. The common nails are made from carbon steel Q195, Q215 or Q235. The common nails can be polished , electro galvanized and hot dipped galvanized finished.
Material: Low carton steel(Q195, Q235)
Designation Number
Inch
Wire Gauge (mm)
Head Width (mm)
Longth (mm)
Length of end(mm)
8#
4"
40.2+-0.03
8.0+-0.1
102±0.1
7.5±0.5
10#
3.5"
3.75+-0.03
7.5±0.01
89±0.1
6.5±0.5
11#
3
3.22+-0.03
7.05±0.01
76±0.1
5.5±0.5
12#
2.5”
3.05+-0.03
6.0±0.1
60±0.1
5.0±0.5
13#
2"
2.75+-0.03
5.5±0.1
51±0.1
5.0±0.5
14#
1.75"
2.42+-0.03
4.8±0.1
45±0.1
5.0±0.5
15#
1.5"
1.90+-0.03
4.3±0.1
38±0.1
4.0±0.5
16#
1.25"
1.72+-0.03
4.0±0.1
32±0.1
4.0±0.5
17#
1"
1.72+-0.03
3.5±0.1
25±0.1
4.0±0.5
18#
0.8"
1.52+-0.03
3.5±0.1
19±0.1
3.5±0.5
Head: checkred round head countersunk
Shank: Smooth
Point: sharp diamont point
Diameter: BWG5-18
Length: 1/2''-8''
Finish: Polished, E.G., H.D.G
Key words: polished nails, nails for building construction, common wire nails
